 KMW Products
Loaders
 To find out which KMW front-end loader model is right for your tractor,
click here.

    Backhoes
Available as
OEM Product Only

Hydraulic Oil Supply Routing

Lift Cylinder Rods

KMW Product Features

KMW loaders have a low profile, modern appearance, and are engineered for today's tractors.
Purchase base loader now and add features and attachments as your operation requires.
Let us introduce you to our Front-End Loader Features

KMW Front-End Loader Features
In addition to specific features on individual models, all KMW front end loaders have these outstanding qualities you'll appreciate:

  • Thick, high-strength materials used throughout all components
  • Purchase base loader now and add features and attachments as your operation requires
  • Replaceable steel wear bushings located at critical pivot points
  • Large radius side plates for modern appearance and improved strength
  • Powder Coating to Match
  • Heavy duty attachment linkages increase dump and rollback angles (Not Available on Model 1750)
  • Hydraulic oil supply hoses are routed inside boom arm
    • Increases operator's visibility
    • Protects the hydraulic components
    • Enhances appearance
  • Grease fittings conveniently located for easy lubrication
  • Powder coat painted to match your tractor color
  • High quality cylinders
  • Reinforcement Doublers located in areas of high stress
  • Solenoid Operated Comfort Drive
  • Optional Solenoid operated comfort drive
    • Improves operator comfort
    • Reduces strain on tractor/loader frame
    • Increases productivity
    • Extends unit's life
  • Optional single lever hydraulic disconnect
  • Optional loader valve with solenoid operated 3rd function
  • Optional 2 way hydraulic self-leveling
    (Not available on Model 1750)
    • Less wear points
    • Improved rollback angle
    • Low profile

KMW Front-End Loader Attachments
featuring Euro-style quick attach

  • Grapples
    • Choose 4 or 6 tine -- both have rugged 3/4" tines and dual cylinders
  • Heavy duty buckets (Other bucket options are available.  Consult KMW)
    • Available in 3 widths: 84", 96" & 102"
    • 3" x 5" upper box cross tube
    • 3/4" x 6" cutting edge
    • 4 heavy duty wear bars
    • Reinforced side plates
    • Grapple ready
  • Optional Grill Guards (Note: Model 1750 grill guard integrated into loader)
  • Pallet Forks
  • Bale Spears


Product Specifications 1220 1440 1660 1750 1760 1860
Tractor HP 45-80 60-110 80-130 90-180 110-190 140-255
Maximum Lift Height
to Pivot Point
10'-4" 11'-8" 12'-10" 13'-8" 13'-8" 15'
Clearance with Bucket
Fully Dumped
8'-2" 9'-2" 10'-1" 11'-5" 11'-5" 12'-4"
Reach at Maximum Lift Height 2'-2" 3'-8" 2'-8" 3'-6" 4'-2" 2'
Dump Angle 40° 42° 42° 37° 40° 40°
Reach with Bucket on Ground 6'-1" 7' 7'-5" 7'-10" 8'-5" 8'-7"
Rollback Angle 17° 30° 32° 25° 32° 32°
Dig Depth 5.5" 4.75" 4" 4" 3" 3"
Lift Capacity to Maximum
Height at Pivot Point
3609# 4400# 4750# 4500# 5600# 6400#

We design loaders to fit AGCO, Buhler, Case International, John Deere, McCormick and New Holland tractors. Click here to check for your make and model.

Specifications based on ASAE Standards 5301.3 and furnished for
general information as they can vary with different tractor models.
